Blackmagic Design SWATEMMINICEXTISOG2, ATEM Mini Extreme ISO G2 HDMI Broadcast Switcher

Blackmagic Design SWATEMMINICEXTISOG2, ATEM Mini Extreme ISO G2 HDMI Broadcast Switcher

ATEM Mini Extreme ISO G2 is a powerful yet compact live switcher for building a high-end broadcast studio. Get an expanded professional style control panel with built in streaming, 8 standards converted HDMI inputs, 3 independent HDMI outputs, built in streaming engine, multi-view, CFexpress and Thunderbolt for record/playback. There is also 10G Ethernet for fast network storage access, XLR audio inputs, USB webcam, DVE, chroma key, media player and ISO recording of all 8 video inputs.

The switcher is ideal for interviews as you can connect multiple cameras for close-ups of the host or interviewee, as well as wide shots of the space. Plus, ATEM Mini is so small the operator can even switch in small studios.
The ATEM Mini ISO G2 has a built-in hardware streaming engine for live streaming via the Ethernet connection without the need for a computer. That means you can live stream to YouTube, Facebook, and Twitch with high quality without dropped frames and with simpler settings. Just select the streaming service and enter the streaming key.

• 8-Channel HDMI Live Streaming Switcher
• All-New Design, Supports up to 1080p60
• 1G & 10G Ethernet Ports, CFexpress Slot
• 3 Independently Assignable HDMI Outputs
• 26-Input, 2-Channel Audio Mixer
• Input Frame Rate & Format Converter
• MADI Input, Analog Line/Mic XLR Inputs
• HD Multiview Output with up to 16 Views
• Dual USB-C & Thunderbolt Ports
• 4 Upstream, 2 Downstream Keyers

Connections

• Total Video Inputs: 9
• Total Outputs: 4
• Total Aux Outputs: 4
• SDI Rates: 1.5G, 3G
• HDMI Video Inputs:
  • 8x HDMI type A, 10-bit HD switchable
  • 2-ch embedded audio
• HDMI Video Outputs: 3
• HDMI Program Outputs: 3
• Total Audio Inputs:
  • 2x XLR Combo with phantom power
  • 1x BNC 32 Ch MADI digital audio
• Total Audio Outputs: 1x 6.35mm headphone jack
• Video Input Re-Sync: On all 8 HDMI inputs and remote sources
• Frame Rate and Format Converters: On all 8 HDMI inputs and remote sources
• Webcam Output: 2x USB-C supporting 720p or 1080p at PGM frame rate
• Total Multi Views:
  • 1x HDMI
  • 1x Webcam
• Control Panel Connection: Ethernet. Direct connection between panel and chassis, or via network
• Internal Timecode Generator: Yes
• Tally Output: On Blackmagic HDMI and remote cameras
• Ethernet:
  • 1x 1G Ethernet for simple streaming, control panels and internet connection
  • 1x 10G Ethernet connection for recording
• Computer Interface:
  • 1x USB Type-C 3.1 Gen 1
  • 1x Thunderbolt for fill key video out, video input, ethernet to storage, and power

Audio

• Audio Mixer:
  • 26 input x 2-ch mixer.
  • Selectable On/Off/Audio-Follow-Video per channel plus separate gain control per channel
  • Level and Peak metering. Plus new Fairlight audio enhancements: Compressor, Gate, Limiter, 6 bands of parametric EQ. Master gain control.
• Analog Input: Balanced stereo XLR combo connectors
• Analog Input Delay: Up to 8 frames
• Mic Plug In Power: +48V phantom power

Recording

• Direct Recording Video and Audio:
  • CFExpress slot for recording
  • Network Recording
  • USB-C Recording
• Video Recording:
  • 8x HDMI ISO inputs as H.264 .mp4 files at up to 70Mb/s quality at the ATEM video standard with AAC audio.
  • 1x Program out as H.264 .mp4 file at the Streaming quality setting and at the ATEM video standard with AAC audio.
• Audio Recording: 26x 2-ch audio inputs recorded as separate 24-bit 48kHz .wav files. Including 1 analog 2-ch audio input, 8x Input source 2 channel embedded audio inputs and 32x MADI audio channels.

Processing

• Audio Mixer:
  • 58 Channel mixer
  • Selectable On/Off/Audio-FollowVideo
  • Level and Peak metering
  • Master gain control
  • 6 band parametric EQ, Dynamics including Expander, Gate, Compressor and Limiter

Standards

• HD Video Input: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
• HD Video Output: 1080p23.98, 1080p24, 1080p25,1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
• Video Streaming: 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
• Video Sampling: 4:2:2 YUV
• Color Precision: 10-bit
• Color Space: Rec 709
• HDMI Input Resolutions from Computers:
  • 1280 x 720p 50Hz, 59.94Hz and 60Hz
  • 1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60Hz
  • 1920 x 1080i 50, 59.94Hz and 60Hz
• Colorspace Conversion: Hardware based real time
