Bolin N2-210X, NDI HX3 FHD PTZ Camera, 10x Zoom

Bolin N2-210X, NDI HX3 FHD PTZ Camera, 10x Zoom

The Bolin N2-210X, FHD NDI HX3 PTZ Cameras provide high-quality Full HD video in a compact and budget-friendly design, making them an excellent choice for live production, video conferencing, studios, Pro AV applications, and houses of worship. Built on Bolin’s Blue Line platform, these cameras offer professional features at an affordable price, without compromising on image quality, industry standards, or smooth PTZ control.

Supports Certified NDI HX3, HDMI, USB, and IP streaming. The N2-210X offers a 10x zoom, providing wide-angle shots ideal for conference rooms and collaborative workspaces. Maintains consistent image quality across all outputs, delivering sharp detail, accurate colors, and smooth motion, whether used for live events, streaming, or professional video calls.

Designed for versatility in any setup, these cameras are compact enough to fit into tight spaces while offering precise PTZ movement for controlled, professional framing. NDI HX3 support ensures efficient, high-quality IP video transmission, reducing bandwidth demands without sacrificing performance.

The N2-210X provides a cost-effective solution for professionals looking for reliable, high-quality video, flexible connectivity, and smooth PTZ operation in a compact, well-built design.

•  Full HD
•  10X Zoom Range, 69° HOV
•  NDI HX3, HDMI, USB

High-Quality Imaging - Full HD
Bolin’s NDI HX3 PTZ cameras are equipped with Sony sensor to provide brilliant, high-quality images in 1080p60 resolutions with 10 to 20x optical zoom.

PTZ Movement
Extremely quiet and smooth operation for Pan/Tilt movements combined with enhanced adaptive, variable, and super slow speed control provides accurate and effective operation experiences. Picture Profile Preset: Image parameter settings restored with presets and quick access operation.

Video Output
N2 NDI HX3 PTZ cameras deliver NDI IP streaming video to network and are fully compatible with NDI-enabled hardware and software, with local HDMI video and USB streaming to PC software for conventional video production and cloud based video conferencing applications. N2-220X camera with 20X zoom range also provides 3G-SDI, lossless baseband video for live production and light broadcast use.

Audio
HDMI/SDI/USB and IP video streaming signal has high–quality audio streaming embedded with support for Mic-in and Line-in audio input.

Video Settings
Image parameter adjustments include exposure, focus, iris, shutter speed, white balance, color matrix, gamma, wide dynamic range, E-flip/mirror and more with configurable video settings.

Camera

• Image Sensor: Sony Progressive scan CMOS image sensor 1/2.8 type
• Number of effective pixels: 1920X1080, 2.13 MP
• Zoom: Optical Zoom 10X,Digital Zoom 16X
• Focal Length: f= 4.34 mm (Wide) to 35.17 mm (Tele)
• Aperture: F1.85 (Wide) to F2.63 (Tele)
• Horizontal Angle of View: 68.8 °(W)~8.8° (T)
• Vertical Angle of View: 39.5° (W)~5.1° (T)
• Min. object distance: 10mm (Wide)
• Min. Illumination: 0.5lux (color), 0.1lux (black)
• Shutter Speed: 1/1 sec to 1/10000 sec (22 steps)
• Focus: Auto,Manual, One Push
• White Balance: Auto,Indoor, Outdoor, OPW, ATW, Manual
• Exposure: Auto, Manual, Shutter/Iris/Brightness priority
• Image Adjustment: Brightness, Color(Saturation), Contrast, Sharpness, HUE
• Back Light Compensation: On/Of

USB

• USB Port: USB2.0 Type C
• Encoder: H.264/YUV2
• USB Video Format: 1920x1080p60/50/30/25fps, 1280X720p60/50/30/25fps
• Compatible Integration: UVC,UAC
• Video Conference Compatibility: Most video conference platform in the market

HDMI

• Video Format - HDMI: 1920x1080p:60/59.94/50/30/29.97/25; 1280x720p:60/59.94/50/30/25
• Color Format: 10bit(HDMI),YCbCr
• Color Space: YUV,RGB
• OSD Menu Display: YES (English,Chinese,Spanish,German,French,Russian)

Network-IP

• Video Codec: NDI HX3
• Network Interface: RJ45 port-Standard 1Gbps Ethernet
• IP Video - 1st Stream: 1920x1080,1280x720; Frame Rate: P60/50/30/25
• IP Video - 2nd Stream: 704x576,640x480,640x360,576x480,352x228,320x240,320x180; P60/50/30/25; Frame Rate P60/50/30/25
• True Dual Output: Video resolution and framerate: IP and HDMI can be output with different format (SDI and HDMI will be the same,SDI is the same or lower than HDMI,USB is the same as IP)
• IP Protocols: TCP/IP,ICMP,ARP,RTP,SIP,UDP,HTTP,HTTPS,DNS,DHCP,FTP,NTP,NDI HX3
• Application Protocols: RTP,RTSP,RTMP,RTMPS,SRT,NDI HX3
• Multi-stream: 2 Streams
• Audio Compression: AAC-LC,G.711,G.726 Broadband Audio Encoding
• Compatible Integration: ONVIF2.4,VISCA Over IP

Interface Connections

• HDMI Video Output: HDMI 1.4X1 Type A
• IP Video Stream: Up to 1080p60
• Camera Control Interface: RJ45X1-RS422, RJ45X1-IP Control, IR Remote Control
• Control Protocol: VISCA. VISCA Over IP, Pelco P/D
• LAN Port: RJ45X1 (1000BASE-T Ethernet port)
• USB Port: USB2.0,Type C
• USB Protocol: UVC,UAC

Mechanical

• Pan Movement: Horizontal:±170 degrees continuous pan (Zoom Adaptive Speed Range: 0.05°?100°/S)
• Tilt Movement: Vertical:+90 degrees to -30 degrees (Zoom Adaptive Speed Range: 0.05°?50°/S)
• Speed Proportional: Pan/Tilt Speed proportional to zoom range
• Preset Position: 255 positions,Speed 150°/s,Accuracy: 0.05° 6 presets on remote controller

General

• Body: Partial Magnesium Alloy
• Mount: Ceiling mount, Wall mount, Tripod
• Size of Tripod Screw Hole: 1/4"-20UNC with safety joint
• Operating Temperature: 32 to 130 (°F)
• Operating Humidity: ≤80% Suitable for Use
• Power Input: DC±12V, PoE+(Compatibable with IEEE802.3at)
• Power Consumption: Min:10W(Static state with no movement); Max:13W(Fully loaded operation)
• Dimension: 5.63"x5.63"x6.34" (LxWxH)
• Weight: 3.5 Lbs (Net weight)
