Overview
Mackie ProFX22v3 22-channel Mixer with USB and Effects
Mackie ProFXv3 Series Effects Mixers with UBS are the Ulimate affordable solution for live sound and studio. Now with Mackie renewed Onyx mic premamps that offer 80dB of headroom, gain hungry mics and instruments sound better than ever. The new GigFX effects engoine offers 24 built-in FX for even more options for adding the finishing touch. Record in 24-Bit/194kHz quality with the 2x4 USB I/O with zero latency. Waveforrm OEM recording software/plugin packages are included.
- 17 Mic Inputs & 14 Mono Mic/Line Inputs
- Inserts on Channels 1-14, Comp on 1-12
- 2-In / 4-Out USB (24-Bit, 192 kHz)
- GigFX Effects Engine (24 FX Presets)
- Main, Control Room, Subgroup Outputs
- 17 Onyx Mic Preamps with 48V Phantom
- 3-Band EQ, Aux Send, FX Send, Pan, Mute
- Level, FX, Sub 1-2, Sub 3-4, Main Faders
Specifications
- Channels: 22 (14 x mono, 4 x stereo)
- Computer Connectivity: USB (2 x 4)
- A/D Resolution: 24-bit/192kHz
- Faders: 22 x 60mm Faders
- Inputs - Mic Preamps: 2 x XLR-1/4" combo (mic/line/Hi-Z), 15 x XLR (mic)
- Phantom Power: Yes
- Inputs - Line: 12 x 1/4", 6 x 1/4" (3 x stereo), 1 x 1/8" (stereo)
- Outputs - Main: 2 x XLR, 2 x 1/4" (L/R), 2 x 1/4" (control room)
- Outputs - Other: 4 x 1/4" (sub group out)
- Aux Sends: 1 x FX Send (post), 2 x Monitor Send (pre), 1 x Monitor Send (pre/post)
- Send/Return I/O: 1 x 1/4" (FX send), 3 x 1/4" (monitor send)
- Busses/Groups: 2 x Sub Group
- Inserts: 14 x 1/4" (channel)
- Headphones: 1 x 1/4"
- USB: 1 x Type B
- Other I/O: 1 x 1/4" (footswitch)
- EQ Bands: 3-band EQ with Variable Mid Frequency (mic channels), 100Hz Low-cut Filter
- Signal Processing: 12 x Channel Compressors
- Effects: GigFX Engine: Reverbs, Chorus, Delay, Flange, Auto-Wah
- Software: Pro Tools First, Waveform OEM DAW, Additional Plug-in packages available
- Power Source: Standard IEC AC cable
- Height: 4.4"
- Width: 17.1"
- Depth: 24.1"
- Weight: 19.8 lbs.
