ADJ FOC750, Focus Spot 7Z Moving Head Luminaire, with Spot & Wash Effects

ADJ FOC750, Focus Spot 7Z Moving Head Luminaire, with Spot & Wash Effects

Part of ADJ’s popular Focus Series of LED-powered moving head luminaires, the Focus Spot 7Z is a potent and feature-rich spot fixture. Its light source is an efficient 420W white (8,000K) LED engine, which has an average operational life of 20,000 hours. Focused through precision-engineered optics, it allows the fixture to generate a bright, punchy and even output of 20,000 Lumens.

An exhaustive collection of beam-shaping tools is packed into the Focus Spot 7Z, equipping lighting designers to fully unleash their creative potential. This begins with an advanced color selection system which combines a variable CMY and CTO (2,700K to 8,000K) color mixing system with a color wheel that features seven dichroic slots (including High CRI and CRB filters).

The fixture features two independent GOBO wheels, each of which incorporate seven slots for interchangeable, indexed-rotating patterns. In addition, it also incorporates an animation wheel with indexed rotation as well as two separate rotating prisms (4-facet circular and 6-facet linear). Motorized zoom (6° ~ 48°), focus and iris are integrated into the optical system as are two separate frost filters (Light to blur GOBO patterns and Heavy to generate a wash output).

• Color: CMY Color Mixing + Variable CTO
• Animation Wheel + Iris
• LED Source: 420W Cool White LED
• Motorized Zoom: 6° ~ 48°
• 2 Prism Wheels

• SOURCE
  • 420W White LED Engine
  • 20,000 Hour Average LED Life
• EFFECTS
  • 4-Facet Circular 6-Facet Linear Rotating Prisms
  • 2 Frost Filters (Light Heavy)
  • Animation Wheel (Rotatable and Indexable)
  • Motorized Zoom (6° ~ 48°) - plus Fine Zoom
  • Motorized Focus (plus Fine Focus)
  • Motorized Iris
  • Electronic Dimming Strobe (1-20Hz)
• COLOR
  • Full CMY color mixing
  • Variable CTO (2,700K to 8,000K)
  • Colors Wheel with 7 dichroic slots (Includes High CRI and CTB Filters)
  • CMY and Color Wheel preset macros
• GOBOS
  • (2) Gobo Wheels
    • #1 - (7) Interchangeable Rotating-Indexing Glass Gobos
    • #2 - (7) Interchangeable Rotating-Indexing Glass Gobos
• CONTROL / CONNECTIONS
  • (3) DMX Channel Modes (30 / 34 / 45)
  • DMX512, Art-Net and sACN protocols
  • Aria X2 Wireless Management / DMX System
  • RDM (Remote Device Management) compliant
  • 6 Button Touch Control Panel
  • Full Color 180° Reversible LCD Menu Display
  • 8 / 16 Bit Resolution Adjustable Movement
  • 5-pin XLR DMX In/Out
  • RJ45 connectors In/Out
  • Locking In/Out power connections
  • With Wired Digital Communication Network
  • 5 Dim Curve Modes
  • 7 Dimmer Modes
  • Adjustable Fan Speeds
  • Adjustable Refresh Rates (900Hz - 25,000Hz)
• PAN / TILT
  • Pan: 540 or 630-degrees
  • Tilt: 270-degrees
  • Fine Pan/Tilt
  • Pan Tilt Locks
• SIZE / WEIGHT
  • Length: 18.8” (477.5mm)
  • Width: 14.7” (374mm)
  • Vertical Height: 25.7” (653mm)
  • Center Spacing: 24.0” (609.6mm)
  • Weight: 51.70 lbs. (23.45kg)
• ELECTRICAL / THERMAL
  • AC 100-240V - 50/60Hz
  • Max Power Consumption: 524W
  • Max ambient temperature: 14°F to 113°F (-10°C to 45°C)
  • Max housing temperature: 136°F (58°C)
• INCLUDED ACCESSORIES
  • Locking Power cable
  • 180mm Omega brackets (x2)
