Bolin R9-418F 1 Inch 4K PTZ Camera, HDMI/6G-SDI, 18x Zoom

Bolin R9-418F 1 Inch 4K PTZ Camera, HDMI/6G-SDI, 18x Zoom

The Bolin R9-418F 1 Inch 4K PTZ camera is engineered for broadcast, live production, and professional AV applications, delivering high-resolution 4K image quality with clarity and depth. Built around a Sony 1-inch CMOS sensor, the R9-418F excels in low-light conditions, ensuring true-to-life colors and exceptional detail even in challenging environments. With 18x zoom and built-in ND filters, it is a perfect fit for broadcast studios, live events, theaters, houses of worship, and corporate productions, where precision and flexibility are essential. Its robust design easily integrates into baseband and AV over IP workflows, with multiple simultaneous outputs, including dual 6G-SDI, HDMI 2.0, Optical SDI, and IP streaming, ensuring professional-grade reliability in any production setting. FPGA hardware FAST HEVC codec provides high-quality, low latency and low bandwidth IP streams include RTSP, RTMP, SRT, ONVIF, and MPEG-TS.

Designed for high-end production environments, the R9-418F features a built-in SFP+ slot for optional 12G-SDI fiber expansion, enabling long-distance, high-bandwidth video transmission. Additionally, FreeD protocol support allows for real-time tracking data output to AR/VR graphics systems, making it a powerful tool for virtual sets and immersive productions. The camera’s industry-leading 255-step precise PTZ movement, optical image stabilization, and flexible mounting options allow for easy installation and operation in studios, auditoriums, and professional live venues.

From studio broadcasts to live productions, the Bolin R9-418F delivers high-quality 4K video, flexible connectivity, and precision PTZ functionality, ensuring every moment is captured with professional-grade quality and reliability

• Sony image block with 1 Inch large 4K sensor
• Zeiss Vario-Sonnar T lens with 18X zoom range
• Resolution 4K 2160p29.97, 1080i59.94, 1080p60
• IP Video Resolution: Up to 2160p30, 1080p60
• Video Output: Simultaneous 6G-SDI, HDMI, IP
• FPGA FAST HEVC Ultra Low Lantency
• SFP Optical SDI video output
• Black Level, Color Matrix, Image Stabilizer
• RTSP. RTMP, SRT Supported
• Visca Over IP, Onvif, FreeD, Serial Control Supported

Camera

• Image Sensor: CMOS image sensor 1/1.8 type STARVIS 2 sensor
• Number of Effective Pixels: 2712 x 1538, 4.17M [pixels]
• Picture Elements: 2688 x 1520, 4.09M [pixels]
• Lens: Enhanced optical zoom 30X
• Digital Zoom: 12X
• Horizontal Angle of View: 58.1° (Wide) - 2.3° (Tele),
• Vertical Angle of View: 34.9° (Wide) - 1.7° (Tele),
• Focal Length: f= 6.5 mm (WIDE) to 162.5 mm (TELE)
• Min. Object Distance: 100mm (Wide), 1200mm (Tele)
• Aperture: F1.6 (Wide) to F4.8 (Tele), 16 steps
• Min. Illumination: ICR-Off, 0.009 lx (1/30 sec, 50%, High Sensitivity On); ICR-On, 0.00008 lx (1/30 sec, 50%, High Sensitivity On)
• Shutter Speed: 1/1 sec to 1/10000 sec (22 steps)
• Focus: Spot Focus, Auto / Manual / One Push Trigger /Full Scan one push trigger / Near Limit / Spot Light Avoidance
• White Balance: Auto / ATW / Indoor / Outdoor / One Push WB / Manual / One push Triger / Outdoor Auto / Sodium Vapor Lamp Auto / Sodium Vapor Lamp / Sodium Vapor Lamp Outdoor Auto
• Exposure: Full Auto / Gain Limit Setting / Shutter Priority / Iris Priority / Manual / EV compensation
• Features: High Sensitivity, Backlight Compensation, HLC, E-FLIP, Mirror, Day/Night
• Gamma: Standard / Straight gamma
• Noise Reduction: On/Off (level 5 to 1 / Off, 6 steps), 3D / 2D

Mechanical

• Pan Movement: PAN: 340° (-170° to +170°); Fully proportional 0.05° to 100°/s
• Tilt Movement: TILT: 120° (-30° to +90°); Fully proportional 0.05° to 75°/s
• Speed Proportional: Pan/Tilt Speed proportional to zoom range
• Preset Position: 255 positions, Speed 100°/s, 0~5 Level Adjustable, Accuracy: 0.1°
• Preset Memory: Picture Profile Preset-Preset Memory for image parameters: Backlight Compensation, White Balance, R-Gain/B-Gain, Auto Exposure, Bright, Iris, Shutter, Gain, Aperture, Effect, Noise Reduction, Mirror, Gamma, Ex-COMP, Color Hue, Contrast etc.)

Interface

• HDMI Video Output: HDMI 2.0 Type A
• SDI Video Output: 3G-SDI, SMPTE424M /SMPTE292M /SMPTE 296M standards, 75? BNC x 2,SDI/PM for output to has OSD display
• SDI Optical Fiber Output A: Optical 12G-SDI (Module Excluded). Detachable slot, Connector: Duplex LC (optional via ST, LC or SMPTE)
• SDI Optical Fiber Output B: Laser Unit: Single-mode 1,310nm DFB-LD transmitter and PIN receiver Complaint with MSA SFP+ Specification SFF-8402.
• Network LAN Port: RJ45X1, Standard 10M/100M/1000M Base-TX Ethernet, LAN connector for IP control/video output/audio output/System FW Upgrade
• Synchronization System: Internal/External synchronization (BBS/Tri-level sync)
• External Sync Input: Genlock, BNC connector, BBS (Black Burst Sync), tri-level sync supported
• Audio Input A: Balanced XLR (Hirose Connector via Atomos 10-Pin LEMO Type to XLR Breakout Cable) with 48V Phantom power
• Audio Input B: 3.5mm TRRS for bidirection audio intercom
• Audio Output A: Balanced XLR (Hirose Connectorvia Atomos 10-Pin LEMO Type to XLR Breakout Cable), embedded with HDMI, SDI, USB and IP
• Audio Output B: 3.5mm TRRS for bidirection audio intercom

HDMI Video Signal System

• HDMI Video Format: 1920 x 1080/59.94p/60p 1920 x 1080/59.94i/60i 1920 x 1080/50p 1920 x 1080/50i 1920 x 1080/29.97p/30p 1920 x 1080/25p 1920 x 1080/23.98p/24p 1280 x 720/59.94p/60p 1280 x 720/50p
• Color Precision: 12bit(HDMI), YUV4:2:2, YUV4:2:0
• Color Space: YUV/RGB

SDI Signal Format

• SDI Video Format: 1920 x 1080/59.94p/60p 1920 x 1080/59.94i/60i 1920 x 1080/50p 1920 x 1080/50i 1920 x 1080/29.97p/30p 1920 x 1080/25p 1920 x 1080/23.98p/24p 1280 x 720/59.94p/60p 1280 x 720/50p
• Color Precision: 10bit(SDI), YUV 4:2:2
• Color Space: YUV
• Standard: SMPTE 292M ,SMPTE 296M (1.5Gb/s), SMPTE 424M, SMPTE 274M,SMPTE 425-A (3Gb/s), SMPTE 2081(6Gb/s), SMPTE 2082-1(12Gb/s) standard / 75Ω (BNC x 1), With SMPTE352 SDI Metadata Supported
• True Dual Output: HDMI and SDI signal can be output with different format
