Eupen Cable EC4-50, 1/2" Foam Coax Cable

Eupen Cable EC4-50, 1/2" Foam Coax Cable

Coaxial cable, 1/2" 50 ohm corrugated copper with black PE jacket

Available Connectors

NM50V12 - N Male

NF50V12 - N Female

NM50VL12 - N Male Right Angle

7/16M50VL12 - 7/16 DIN Male Right Angle

7/16M50V12N1 - 7/16 DIN Male

7/16F50V12N1 - 7/16 DIN Female

EIA78V12N - 7/8" EIA Flange

• Construction:
  • Inner conductor: Copper clad aluminum wire, ⌀ 0.19 in (4.8 mm)
  • Dielectric: Gas-injected cellular polyethylene, ⌀ 0.49 in (12.4 mm)
  • Outer conductor: Corrugated copper tube, ⌀ 0.54 in (13.8 mm)
  • Outer sheath: Polyethylene, ⌀ 0.63 in (16 mm)
• Characteristics:
  • Impedance (Ohm): 50 ± 1
  • Temperature range: -67°F to +185°F
  • Water immersion testing: IP67 & IP68
  • RF peak voltage (kV): 1.6
  • RF peak power (kW): 25.6
  • Cut-off-frequency (GHz): 9.8
  • Insulation resistance (MΩ/km): >> 5000
