Eupen Cable EC7-50-A, 1 5/8" Low Loss Foam Coax Cable

Eupen Cable EC7-50-A, 1 5/8" Low Loss Foam Coax Cable

Coaxial cable, "A" series 1-5/8" 50 ohm corrugated copper with black PE jacket

Available Connectors

• EIA158V158N - 1 5/8" EIA Flange
• EIA78V158N - 7/8" EIA Flange
• 7/16F50V158N1 - 7/16 DIN Female
• 7/16M50V158N1 - 7/16 DIN Male
• NF50V158N1 - N Female
• NM50V158N1 - N Male

• Construction:
  • Inner conductor: Corrugated copper tube, ⌀ 0.70 in (17.7 mm)
  • Dielectric: Microcell gas-injected PE, ⌀ 1.69 in (43 mm)
  • Outer conductor: Corrugated copper, ⌀ 1.83 in (46.6 mm)
  • Outer sheath: Black polyethylene, ⌀ 1.97 in (50.0 mm)
• Characteristics:
  • Impedance (Ohm): 50 ± 1
  • Temperature range: -40°F to +140°F
  • Water immersion testing: IP67 & IP68
  • RF peak voltage (kV): 5.5
  • RF peak power (kW): 302
  • Cut-off-frequency (GHz): 2.8
  • Insulation resistance (MΩ/km): >> 5000
