Overview
Mackie Onyx24, 24-channel Analog Mixer with 24-bit/96kHz Multi-track Recording and Built-in Effects
Musicians, artists, engineers, and broadcast studios looking for a professional-quality compact mixing solution for live audio, home recording, and content creation should look no further than the Mackie Onyx24, a 24-channel mixer with 24-bit / 96 kHz 8x4 multitrack recording and high-gain Onyx preamps.
The Onyx24 is packed with features including British-style Perkins EQ, powerful DSP effects, a full-color display, and integrated stereo recording and playback from an SD card. The mixer provides an end-to-end ultralow-noise design, which delivers the sound quality professionals demand.
- Onyx Preamps
- British-Style Perkins 3-Band EQs
- Premium Analog Circuitry
- Ultralow-Noise Design
- Record & Playback to/from Mac/PC via USB
- Studio Command Full-Color Display
- Robust Digital Effects Engine
- Dedicated Control Room Output
- 12-Segment Stereo Meters
- Includes Powerful Software and Plugins
Record and Playback via SD Card or USB
- High-resolution 96 kHz / 24-bit multitrack (14x4) recording to Mac/PC via USB
- Direct to SD card stereo (2x2) recording and playback
- Channel-assignable 4-track USB return (2 stereo pairs)
- Send your Main Mix to USB via a dedicated switch
Bluetooth Streaming for Wireless Audio Streaming
- Pair your Bluetooth enabled device and stream audio directly to a channel on the mixer
- Streamed audio can be routed to Aux Sends and the Main Mix
Specifications
- Type: Analog Mixer
- Channels: 24
- Computer Connectivity: USB, Bluetooth
- Inputs - Mic Preamps: 18 x XLR
- Inputs - Line: 24 x 1/4", 1 x 1/8"
- Outputs - Main: 2 x XLR (main), 2 x 1/4" (main), 2 x 1/4" (control room)
- Send/Return I/O: 1 x 1/4" (FX), 2 x 1/4" (mon)
- Headphones: 1 x 1/4"
- USB: 1 x Type B
- Bluetooth: Yes
- Other I/O: 1 x 1/4" (footswitch)
- EQ Bands: 4-band EQ
- Effects: Yes
- Storage: SD card slot
- Power Source: Standard IEC AC cable
