Overview
Middle Atlantic BGR-25SA-27LRD, 25RU, 27" Deep Stand Alone Equipment Rack, No Rear Door
The #1 AV rack because it is both Forward and Lever Lock™ compatible providing maximum mounting capacity on and off the rail and a suite of tool-free accessories making rack installations 5Xs faster!
Features
- 25RU
- 27" (686mm) Depth
- The 1st Forward Compatible rack
- Breakthrough design provides high rack strength without extra weight
- Solid sided for system security and to control airflow
- Sides have ganging holes if multiple BGR-SAs are needed
- Accepts Lever Lock™ system tool free cable management accessories
- The 23” width gives you extra room in “no-man’s land” for front-to-back cable management and for mounting small devices on Lever Lock™ freeing up valuable rackspace.
- Innovative side lacing on the Forward rear rackrail provides flexibility for internal cabling and accepts the Forward vertical cable management products.
- Accepts brush grommet rear door kit for a large cable passage without fishing
- Wide open rack top and bottom offer many cabling and cooling options
- Standard front and rear adjustable Forward Rackrail with numbered spaces
Specifications / Documents
- Dimensions & Measurements
- Depth: 27 in (68.6 cm)
- Height: 47.88 in (121.6 cm)
- Panel Width: 19 in (48.3 cm)
- Rack Units: 25 RU
- Shipping Weight: 128 lbs (62.6 kg)
- UL Load Capacity: 3000 lbs (1,360.8 kg)
- Usable Depth: 24.4 in (62 cm)
- Usable Height: 43.88 in (111.5 cm)
- Width: 23 in (58.4 cm)
- Characteristics & Features
- Color: Black
- Federal Ops Country of Origin: USA
- Finish: Black Wrinkle Powder Coat
- Forward Compatible: Yes
- Gangable: Yes
- Handles: 25mm x 150mm Swing Handle
- Material: Steel
- Product Configuration: Frame Only
- Rack Rail Type: Forward Rackrail
- Rear Door: No
- Seismic Rated: Yes
- TAA Compliant: Yes
