Studio Technologies Model 22 Access Station
The Model 22 Access Station works in conjunction with a Studio Technologies' Model 2A Central Controller to provide a 2-channel IFB origination ("talk") location. Two pushbutton switches allow direct access to each of the IFB channels. The switches are backlit for visibility in locations with low ambient light conditions. Each switch also provides a "tally" indication, lighting brightly when their associated IFB channel is active. The carefully optimized circuitry is capable of providing "high-fidelity" IFB audio performance. This is unique in the often-ignored yet critical talent cueing function. Model 22s are typically installed at positions convenient to producers, directors, or other personnel who need to cue on-air talent. Up to four Model 22 units can be connected to, and powered by, a Model 2A Central Controller.
- 2-channel IFB remote panel
- Works with Model 2A Central Controllers
- No external power source required
- Supports mic and line inputs
- Excellent audio quality
- Backlit pushbutton switches
Specifications / Documents
- Power Requirements: 18 Vdc, 25 mA maximum, provided by connected Model 2A Central Controller
- Interconnection: Two DE-9F (9-pin D-subminiature female) connectors. One connector intended to link Model 22 to Model 2A Central Controller. The second connector, wired in parallel with the first, is designed to allow "loop through" installation for connection to additional Model 22(s).
- Pushbutton Switches 2: Type: backlit, momentary, EAO 99-series Lamp Type: incandescent, T-1, bi-pin, 18 V, 26 mA, 0.5 watt equivalent to EAO Switch Corp. 11-903-2, Wamco 0L1100BPE, Lamptronics AS25-8
- Microphone Input:
- Compatibility: 2-wire electret, designed for use with Studio Technologies' Model 11B Gooseneck Microphone Kit (purchased separately)
- Intended Input Level: –25 dBu nominal
- Microphone Power: +5 Vdc, current limited; applied to microphone "high" lead
- Connector: three terminals on a screw terminal strip
- Line Input:
- Type: electronically balanced, capacitor coupled, compatible with balanced or unbalanced audio signals
- Input Impedance: 24 k ohms
- Common Mode Rejection: 100 dB at DC and 60 Hz, 70 dB at 20 kHz, 62 dB at 40 kHz (typical)
- Input Level: –15 to +10 dBu, input level adjustable via trim potentiometer
- Connector: two terminals on a screw terminal strip
- Mounting: rack mounted using Model 25B 19-Inch Rack Adapter (purchased separately), panel mounted using Model 28A Panel Adapter (purchased separately); custom mounting easily accomplished
