Overview
StudioHub SH-ONOFFCOUGH ON/OFF COUGH MUTE Control Panel.
ON/OFF buttons will switch the mic on/off and the “COUGH” button will momentarily mute the mic audio. All buttons are LED lit to indicate status. RJ-45 (StudioHub+) and barrier strip I/O connections are provided as well as +15VDC in parallel with the ON lamp to close a remote relay for speaker MUTE control.
- Controls: Dedicated ON, OFF, and momentary "COUGH" buttons.
- Indicators: LED-lit buttons show the live microphone status.
- Connections: Equipped with RJ-45 (StudioHub+) and barrier strip I/O connections.
- Relay Output: Includes a +15VDC output in parallel with the ON lamp to trigger a remote speaker mute relay.
Requires Power Supply
