ADJ WMS426, WMS1 Media Sys Portable LED Digital Signage Display

ADJ WMS426, WMS1 Media Sys Portable LED Digital Signage Display

The WMS1 Media Sys is a cutting-edge LED video display designed to elevate retail environments, trade shows, and live events. This all-in-one system includes two WMS1 LED video panels, a display stand with a built-in Novastar video processor, and a durable flight case for easy transport.

The LED video panels feature an ultra high-res 1.95mm pixel pitch with a brightness of 800 NITS, the WMS1 ensures vivid visuals and crisp detail, even in well-lit areas. Its 3840Hz refresh rate and ≥14-bit grayscale deliver smooth, flicker-free playback for videos, animations, and real-time messaging.

Designed for effortless setup and maintenance, the system utilizes a "Roll and Set" installation method with accessible front maintenance. The Novastar TB50 processor and A8s-N receiving card enable seamless content management, while energy-efficient LED technology minimizes power usage. Users can conveniently manage content via computer, mobile devices, USB drives, and cloud-based platforms.

• Transport: Single System Flight Case
• One WMS1 Media System
• Installation Method: Roll and Set
• Maintenance: Front

• Displays
  • Pixel Pitch (mm): 1.95
  • Pixel Density (dot/m2): 262,144
  • LED sealing Type: SMD1212
  • Module Size (mm x mm): 250 x 250mm
  • Module Resolution (PX x PX): 128 x 128 Dots
  • Panel Resolution (PX x PX): 512 x 256
  • Average Life (Hours): 50,000
• Optical Ratings:
  • Brightness (cd/m2): 800 NITS
  • Horizontal Viewing Angle (Deg): 160
  • Vertical Viewing Angle (Deg): 140
  • Grey Scale (Bit): ≥14
  • Refresh Rate (Hz): 3840
• Power Supply:
  • Input Voltage (V): 100-240VAC
  • Max Power Dissipation (W/m²): 520
  • Average Power consumption (W/m²): 180
• Control System:
  • Receiving Card in WMS2 Panels: Novastar A8s-N
  • Processor: Novastar TB50
• Environmental:
  • Working Environment: Indoor
  • IP Rating: IP20
  • Working Temperature (℃):-20~ +40
  • Work humidity (RH): 10%~90%
  • Storage temperature range:-40~ +80
  • Operation humidity (RH):10%~90%
• Weight / Dimensions:
  • Flight Case Dimensions (LxWxH): 45.50" x 28.25" x 27.25" (1155 x 714 x 689.52mm)
  • System Dimensions (LxWxH): 26.76” x 19.68” x 84.3” (679.6 x 499.8 x 2141mm)
  • LED Panel Thickness: 1.32" (33.4mm)
  • System Weight (In Flight Case): 176lbs. (80kg)
