ADJ WMS439, WMS2 Media Sys Portable LED Digital Signage Display

ADJ WMS439, WMS2 Media Sys Portable LED Digital Signage Display

The ADJ Lighting WMS2 Media Sys is a powerful LED display solution equipped with two WMS2 LED panels, an integrated Novastar processor, and a rugged flight case. Boasting a 2.6mm pixel pitch, vivid visuals, and hassle-free setup, it’s ideal for retail, events, and dynamic digital signage.

The WMS2 Media Sys is a state-of-the-art LED video display designed to enhance retail spaces, trade shows, and live events. This all-in-one system includes two WMS2 LED video panels, a display stand with an integrated Novastar video processor, and a durable flight case for effortless transport. Featuring an ultra-high-resolution 2.6mm pixel pitch and a brightness of 700-800 NITS, the WMS2 delivers vivid visuals and crisp details, even in well-lit environments. Its 3840Hz refresh rate and ≥14-bit grayscale ensure smooth, flicker-free playback for videos, animations, and real-time messaging.

Engineered for convenience, the system supports a "Roll and Set" installation method with front-access maintenance. The Novastar TB50 processor and A8s-N receiving card enable seamless content management, while energy-efficient LED technology minimizes power consumption. Designed for indoor use, the WMS2 Media Sys operates in a temperature range of -20°C to 40°C and features an IP20 rating for durability. The ETL-certified WMS1 LED panels ensure reliability and compliance with industry standards.

• Transport: Single System Flight Case
• One WMS2 Media System
• Installation Method: Roll and Set
• Maintenance: Front

System includes:

• 1x WMS2 Media System: 2x WMS2 LED Video Panels
• 1x Display Stand with Built-In Novastar Video Processor
• 1x Flight Case

• Displays
  • Pixel Pitch (mm): 2.6
  • Pixel Density (dot/m2): 147,456
  • LED sealing Type: SMD1515
  • Module Size (mm x mm): 250 x 250mm
  • Module Resolution (PX x PX): 96 x 96 Dots
  • Panel Resolution (PX x PX): 384 x 192
  • Average Life (Hours): 50,000
• Optical Ratings:
  • Brightness (cd/m2): 700-800 NITS
  • Horizontal Viewing Angle (Deg): 160
  • Vertical Viewing Angle (Deg): 140
  • Grey Scale (Bit): ≥14
  • Refresh Rate (Hz): 3840
• Power Supply:
  • Input Voltage (V): 100-240VAC
  • Max Power Dissipation (W/m²): 520
  • Average Power consumption (W/m²): 180
• Control System:
  • Receiving Card in WMS2 Panels: Novastar A8s-N
  • Processor: Novastar TB50
• Environmental:
  • Working Environment: Indoor
  • IP Rating: IP20
  • Working Temperature (℃):-20~ +40
  • Work humidity (RH): 10%~90%
  • Storage temperature range:-40~ +80
  • Operation humidity (RH):10%~90%
• Weight / Dimensions:
  • Flight Case Dimensions (LxWxH): 45.50" x 28.25" x 27.25" (1155 x 714 x 689.52mm)
  • System Dimensions (LxWxH): 26.76” x 19.68” x 84.3” (679.6 x 499.8 x 2141mm)
  • LED Panel Thickness: 1.32" (33.4mm)
  • System Weight (In Flight Case): 176lbs. (80kg)
