Studio Technologies M232, Announcer’s Console with Dante Audio-over-Ethernet
The Model 232 Announcer's Console provides a combination of high-performance audio with an extensive set of user features and configurable resources. The unit is intended for use in demanding broadcast sports, eSports, live event, entertainment, and streaming broadcast applications. With a few simple connections, the Model 232 can provide one on-air talent with all the resources needed to support a wide range of applications. The compact, rugged steel enclosure is intended for tabletop use, small enough for use "court-side" or in a crowded booth, yet flexible enough for remote production deployment. The Model 232 supports Dante® audio-over-Ethernet digital media technology with AES67 compatibility for integration into contemporary applications.
Features
- Compact unit supports one on-air location
- Dante audio-over-Ethernet technology
- Microphone preamplifier with selectable gain and P48 power
- One main and two talkback output channels
- User-controlled headphone mixing
- Superior audio quality
- Redundant Dante with two GigE interfaces
- PoE and 12 Vdc powering
- Extensive feature configuration using STcontroller application
- Supports REMI/At-Home applications
Specifications / Documents
Network Audio Technology:
- Type: Dante audio-over-Ethernet
- AES67-2018 Support: yes, selectable on/off
- Dante Domain Manager (DDM) Support: yes
- Ethernet Interface Configuration: Switched or Redundant
- Bit Depth: 16, 24, or 32
- Sample Rate: 48 or 96 kHz
- Pull-Up/Down Support: no
- Dante Transmitter (Output) Channels: 6
- Dante Receiver (Input) Channels: 7
- Dante Audio Flows: 32; 16 transmitter, 16 receiver
- Internal Digital Audio Processing: 32-bit, fixed
- Input-to-Output Audio Processing Latency: <200 uSec
- Nominal Dante Receiver (Input) and Transmitter (Output) Level: –20 dBFS
Network Interfaces:
- 2, Primary-PoE and Secondary
- Type: 1000BASE-T Gigabit Ethernet (GigE) per IEEE® 802.3ab (10 and 100 Mb/s not supported)
- Power-over-Ethernet (PoE): per IEEE 802.3af (applicable to the Primary-PoE network connection only)
Analog Microphone Input:
- Compatibility: dynamic or phantom-powered microphones
- Type: balanced, capacitive coupled
- Impedance: 3.6 k ohms, nominal
- Gain: 20 to 65 dB in 1-dB steps
- Frequency Response: 20 Hz to 22 kHz, +0/–1 dB
- Distortion (THD+N): <0.0004%, 1 kHz, –4 dBFS output, 20 dB gain, 22 kHz BW
- Dynamic Range: 120 dB, ref 0 dBFS output, 20 dB gain, A-weighted
- Phantom Power: P48 per IEC 61938 standard, on/off selectable with status LED
Limiter Function:
- Type: digitally controlled analog
- Application: applies only to analog microphone input, selectable on/off
- Threshold: 12 dB above nominal level (–8 dBFS)
- Minimum On Time: 30 milliseconds
- Maximum Attenuation: 16 dB at 36 dB or greater microphone preamplifier gain
Analog Microphone Output:
- Type: passive via two 200 ohm resistors from microphone input (will pass phantom power in either direction)
- Muting: solid-state relay contacts, 60 dB attenuation @ 1 kHz
Headphone Output:
- Type: analog 2-channel (stereo)
- Compatibility: stereo (dual-channel) or monaural (single-channel) headphones, headsets, or earpieces with nominal
- impedance of 50 ohms or greater
- Maximum Output Voltage: 3.0 Vrms, 1 kHz, 150 ohm load
- Frequency Response: 20 Hz to 20 kHz, +0/–1 dB
- Dynamic Range: >102 dB, A-weighted
- Distortion (THD+N): <0.025%, measured at 1 kHz, 0 dBu output
Talkback Input Low-Pass Filter (LPF):
- Function: active only when specific talkback channel has tone detect function enabled
- Type: digital, 8-pole Butterworth (48 dB/octave)
- Cutoff: –3 dB at 12 kHz
Connectors:
- Analog Microphone Input: 3-pin female XLR
- Analog Microphone Output: 3-pin male XLR
- Headphone Output: 3-conductor ¼-inch jack
- Ethernet: 2, Neutrik NE8FBH etherCON RJ45 receptacles
- DC Input: 4-pin male XLR (pin 1 negative, pin 4 positive)
- USB: type A receptacle (used only for updating firmware)
- Remote Control Inputs / Tally Output: 2, 3-pin headers located on the main circuit board
- Headphone Output: 3-pin header located on the main circuit board
- DC Output: 3-pin header located on the main circuit board
- Analog Microphone Input: 3-pin header located on the analog circuit board
Power Sources:
- Power-over-Ethernet (PoE): class 3 (mid power, ≤12.95 watts) per IEEE 802.3af
- DC Input: 10 to 18 volts DC, 0.55 A maximum at 12 volts DC (can be powered by optional PS-DC-02, not included)
Dimensions (Overall):
- 6.5 inches wide (16.5 cm)
- 2.9 inches high (7.4 cm)
- 4.9 inches deep (12.5 cm)
