Overview
The Mackie 1202VLZ4 12-Channel Compact Mixer features high-quality Onyx preamps in a compact mixer design with the high-headroom / low-noise performance your professional applications demand.
The mixer is built-like-a-tank with a rugged solid-steel chassis and high-contrast controls for discernible tactile control. With features like a dedicated control room section, it offers a step up in flexibility and performance that is suitable for your professional applications.
- For Sound Reinforcement Applications
- 4x Onyx Preamps
- 3-Band EQ
- 48V Phantom Power
- Low Noise, High Headroom
- Solid Steel Chassis
- Multi-Voltage Power Supply
Specifications
- Type: Analog
- hannels: 12
- Inputs - Mic Preamps: 4 x XLR (CH 1-4)
- Phantom Power: 4
- Inputs - Line: 4 x 1/4" (CH 1-4), 8 x 1/4 (CH 5-12 Stereo), 2 x RCA (Tape)
- Outputs - Main: 2 x XLR, 2 x 1/4"
- Outputs - Other: 2 x RCA (Tape), 2 x 1/4" (Control Room), 1 x 1/4" (Alt)
- Aux Sends: 1 x Pre/Post, 1 x Post
- Send/Return I/O: 2 x 1/4" (Send), 4 x 1/4" (Return)
- Busses/Groups: Alt 3-4
- Channel Inserts: Yes (CH 1-4)
- Headphones: 1 x 1/4"
- EQ Bands: 3-band
- Rackmountable: Yes
- Height: 3"
- Width: 11.9"
- Depth: 10.7"
- Weight: 6.5 lbs.
